Gevind tappe/bakker på lager



Gevindtabel i pdf-format

Metrisk system:

Metriske tappe:
M3
M3,5
M4
M5
M6
M7
M8    M8x1
M9x1,25
M10    M10x1 (VEB WZM)    M10x1,25    M10-26/inch
M11x1,5
M12    M12x1,25    M12x1,5
M13x1 (VEB WZM)    M13-26/inch
M14    M14x1
M16
M18x1,5
M20
M22x1,5

Metriske bakker:
M3
M4
M5
M6
M7
M8
M10    M10x1 (VEB WZM)    M10x1,25    M10-26/inch
M12    M12x1    M12x1,25
M13x1 (VEB WZM)    M13-26/inch
M14x1,5    M14x2
M16
M18x1    M18x1,5
M20
M22
M24
M30

Tommer:

Whitworth tappe:
1/8
5/32
3/16
1/4
5/16
3/8
7/16
1/2
9/16
5/8
3/4
7/8
1 1/8
1 1/4

Whitworth-rørgevind tappe:
1/8
1/4
3/8
1/2
3/4
1
1 1/4

Whitworth-fingevind tappe:
1/4-26
5/16
3/8
7/16

UNF tappe (SAE):
10-32
1/4
5/16
7/16
1/2
5/8
3/4

UNC tappe:
6-32
8-32
1/2

Andre tappe:
1/4-32/inch
9/16-20/inch
9/16-20/inch Links

Whitworth bakker:
5/32
3/16
1/4
5/16
3/8
7/16
1/2
5/8
3/4
7/8
1 1/8
1 1/4

Whitworth-rørgevind bakker:
1/8
1/4
3/8
3/8 Links
1/2
3/4
1

Whitworth-fingevind bakker:
3/8

UNF bakker (SAE):
5/16
3/8
7/16
9/16
5/8
3/4

UNC bakker:
-

Andre bakker:
1/2-24/inch
1-24/inch
